FEATURE:
-- High performance robot servo
-- High-precision metal gears with hard anodizing
-- Full CNC aluminium hulls and structure
-- High quality coreless motor
-- Dual ball bearings

SPECIFICATIONS:
Dead band: 2μs
Neutral point: 1500μs
Pulse width：500μs-2500μs
Motor: Coreless
Max angle：180°±2°
Frequence: 330hz
Voltage：5.0V/7.2V/8.4V
Operating Speed(5.0V/7.2V/8.4V): 0.14/0.12/0.10sec/60°
Stall torque(5.0V/7.2V/8.4V): 31/33.5/38 kg.cm
Demension: 40X20X40mm
Weight:  76 g
Connector Wire Length: JR  265mm
Spline Count: 25T
Tooth Count: 25
