JX Servo RD-C7638MI-360 38kg 360 degree CNC Magnetic Induction Digital Metal Gear HV Servo Robotics Education Industrial
$34.40
Skip to product information
JX Servo RD-C7638MI-360 38kg 360 degree CNC Magnetic Induction Digital Metal Gear HV Servo Robotics Education Industrial
$34.40
Product Specifications
FEATURE
- Magnetic induction potentiometer
- High performance robot servo
- High-precision metal gears with hard anodizing
- Full CNC aluminium hulls and structure
- High quality coreless motor
- Dual ball bearings
SPECIFICATIONS
| Dead band | 2μs |
| Neutral Point | 1500μs |
| Pulse Width | 500~2500μs |
| Motor | Coreless |
| Max Angle | 360° ±2° |
| Frequency | 330hz |
| Voltage | 5.0V / 7.2V / 8.4V |
| Operating Speed (5.0V / 7.2V / 8.4V) | 0.14 / 0.12 / 0.10 sec/60° |
| Stall Torque (5.0V / 7.2V / 8.4V) | 31 / 33.5 / 38 kg.cm |
| Dimensions | 40x20x40mm |
| Weight | 76 g |
| Connector Wire Length | JR 265mm |
| Tooth Count | 25T |
